The DJI RC Plus 2 Enterprise remote controller features a new high-brightness screen that remains clearly visible even in sunlight. It supports IP54 protection and can operate in temperatures ranging from -20°C to 50°C. Utilizing the O4 video transmission system, it features a built-in high-gain antenna array for powerful performance; it also supports a hybrid SDR and 4G video transmission solution, delivering stable and smooth video transmission in both urban high-rise buildings and mountainous environments.
Equipped with a brand-new high-brightness screen, it remains clearly visible even in sunlight. It supports IP54 protection and can operate in temperatures ranging from -20℃ to 50℃. Utilizing the O4 video transmission industry version, it also supports SDR and 4G hybrid video transmission solutions.
1. Please be sure to download and read the user manual and safety summary for the aircraft from the DJI website, and read them carefully before using it.
2. If the remote control is not operated properly, the aircraft may cause injury or damage to people and property. Please pay attention to safety.
3. During use and transportation, please take care to protect the remote control and avoid external impacts to prevent damage to the display screen, joystick, and other components.
Remote control × 1
OcuSync
Operating frequencies*: 2.4000-2.4835 GHz; 5.150-5.250 GHz; 5.725-5.850 GHz
Equivalent Isotropic Radiated Power (EIRP):
2.4 GHz: < 33 dBm (FCC); < 20 dBm (CE/SRRC/MIC)
5.1 GHz: < 23 dBm (FCC/CE)
5.8 GHz: < 33 dBm (FCC); < 14 dBm (CE); < 30 dBm (SRRC)
Wi-Fi
Protocol: 802.11 a/b/g/n/ac/ax
Operating frequencies*: 2.4000-2.4835 GHz; 5.150-5.250 GHz; 5.725-5.850 GHz
Equivalent Isotropic Radiated Power (EIRP):
2.4 GHz: < 26 dBm (FCC); < 20 dBm (CE/SRRC/MIC)
5.1 GHz: < 26 dBm (FCC); < 23 dBm (CE/SRRC/MIC)
5.8 GHz: < 26 dBm (FCC/SRRC); < 14 dBm (CE)
Bluetooth
Protocol: Bluetooth 5.2
Operating frequency: 2.4000-2.4835 GHz
Equivalent Isotropic Radiated Power (EIRP): < 10 dBm
General
Model: TKPL2
Built-in battery: Lithium-ion battery (6500 mAh @ 7.2 V), chemistry: Lithium nickel cobalt aluminum oxide
Charging method: We recommend using a USB-C fast charger with a maximum power of 100 watts.
Rated power consumption: 12.5 watts
GNSS: GPS + Galileo + BeiDou
Video output port: HDMI Type A
Operating ambient temperature: -20℃ to 50℃
Storage temperature:
-30℃ to 45℃ (within one month)
-30℃ to 35℃ (more than one month but less than three months)
-30℃ to 30℃ (more than three months but less than one year)
Charging ambient temperature: 5℃ to 40℃
* The operating frequency bands supported by different countries/regions and their corresponding availability vary. Please refer to local laws and regulations for details.
DJI Matrice 4D Series
DJI Matrice 4T Industrial Series Models
DJI Matrice 4E Industrial Series Models
DJI Matrice 400
